Concrete Batching Plants Official Website for Haomei Machinery
Brief Introduction：This table include the most detailed parameters of China stationary concrete batching plants. Concrete mixing plants of various models are available here.
We supply stationary concrete batching plants of various models. Detailed parameters of our concrate batghing and mixing plant are as below. Welcome to send inquiries by leaving a message here or sending email to april@concretebatchplant24.com.
| item | Model | |||||||
| HZ60G | HZ90G | HZ120G | HZ90/2HZS180 | HZ120/2HZS240 | HZ180/2HZS360 | |||
| 1 | Theoretical capacity | 60m3/h | 90m3/h | 120m3/h |
90m3/h, 180m3/h |
120m3/h, 240m3/h |
180m3/h, 360m3/h |
|
| 2 | Mixer model | JS1000 | JS1500 | JS2000 | JS1500 | JS2000 | JS3000 | |
| 3 | Mixer power | 2*22KW | 2*30KW | 2*37KW | 2*30KW,4*22KW | 2*37KW,4*37KW | 2*55KW,4*55KW | |
| 4 | Cycle time | 60s | 60s | 60s | 60s | 60s | 60s | |
| 5 | Mixer capacity | 1000L | 1500L | 2000L | 1500L | 2000L | 3000L | |
| 6 | Max. Aggregate size | ⌀80mm | ⌀80mm | ⌀80mm | ⌀80mm | ⌀80mm | ⌀80mm | |
| 7 | Powder silo capacity | 2*50t | 2*100t | 2*100t | 4*100t, 8*100t | 4*200t, 8*200t | 4*200t, 8*200t | |
| 8 | Distributor capacity | 1600L | 2400L | 3200L | 2400L | 3200L | 4800L | |
| 9 | Aggregate silo capacity | 3*17m3 | 3*17m3 | 3*17m3 | 4*15m3, 8*15m3 | 4*25m3, 8*25m3 | 4*30m3, 8*30m3 | |
| 10 | Aggregate types number | 3 | 3 | 3 | 4 | 4 | 4 | |
| 11 | Aggregate lift productivity | 140t/h | 210t/h | 280t/h | 500t/h | 700t/h | 700t/h | |
| 12 | Screw conveyor productivity | 110t/h | 110t/h | 110t/h | 80t/h | 110t/h | 110t/h | |
| 13 | Discharge height | 4.1m | 4.1m | 4.2m | 4.1m | 4.2m | 4.3m | |
| 14 | Installed capacity | ~100kw | ~160kw | ~210kw | ~164kw/2*164kw | ~210kw/2*210kw | ~250kw/2*250kw | |
| 15 | Aggregate weighing scope | (0-3000)±2%kg | (0-5000)±3%kg | (0-5000)±3%kg | (0-2000)±2%kg | (0-3000)±2%kg | (0-3000)±2%kg | |
| 16 | Cement weighing scope | (0-900)±2%kg | (0-1200)±2%kg | (0-1200)±2%kg | (0-900)±2%kg | (0-1200)±2%kg | (0-1800)±2%kg | |
| 17 | Powder weighing scope | (0-600)±2%kg | (0-500)±2%kg | (0-500)±2%kg | (0-1000)±2%kg | |||
| 18 | Water weighing scope | (0-300)±2%kg | (0-400)±2%kg | (0-400)±2%kg | (0-400)±2%kg | (0-600)±2%kg | (0-800)±2%kg | |
| 19 | Additive weighing scope | (0-20)±1%kg | (0-50)±1%kg | (0-50)±1.5%kg | (0-50)±1.5%kg | (0-50)±1.5%kg | ||
