Wet concrete batching plant is one of our most popular products. It uses a twin shaft mixer, so the wet concrete batching plant can mix plastic concrete, dry hard concrete and other aggregate. In addition, wet concrete batching plant by the hybrid system, aggregate supply system, weighing systems, control systems and other accessories.
Our company is a professional engineering machinery manufacturer. With our extensive experience, we are able to ensure that our wet concrete batching plant are of high quality and reliability.
At present, we can provide concrete mixing plants, concrete mixer, concrete pump and other construction machinery. In addition, we also have skilled workers and engineers, so we can provide technical services to customers.
Features of Wet Concrete Batching Plant
1. Patented main mixer optimized design, long life and high performance.
2. Microcomputer control and electronic scale weighing to ensure high measurement accuracy and small errors.
3. Mixing system selection of spiral mixing system, high efficiency, scale plate and mixing blades with high rigidity, high toughness wear-resistant alloy steel shell, to extend the service life.
4. Lubrication system uses advanced centralized oil lubrication system to facilitate oil supply, the system is equipped with over-voltage warning and low oil alarm, safe and reliable.
Application of Wet Concrete Batching Plant
Applicable to water conservancy, electricity, roads, tunnels, bridges and port terminals of the wet concrete batching plant.
Models and Technical Specifications
| Type | HZS60 | HZS90 | HZS120 | HZS180 | HZS240 | |
| Theoretical production(m3/h) | 60 | 90 | 120 | 180 | 240 | |
| Concrete mixer | Type | JS1000 | JS1500 | MAO3000/2000 | MAO4500/3000 | MAO6000/4000 |
| Power(KW) | 18.5 | 65.5 | 74 | 110 | 150 | |
| Discharging capacity(L) | 1000 | 1500 | 2000 | 3000 | 4000 | |
| Aggregate size(Pebble/Macadam)(mm) | 80/60 | 80/60 | 80 | 150 | 150 | |
| Aggregate Bin volume(m3) | 8.38 | 12 | 20 | 30 | 40 | |
| Belt conveying Capacity(t/h) | 300 | 450 | 550 | 650 | 900 | |
| Weighing Accuracy | Aggregate (KG) | 3000Kg ±2% | 3000Kg ±2% | 2200Kg ±2% | 3000Kg ±2% | 4200Kg ±2% |
| Cement(KG) | 1500Kg ±1% | 1500Kg ±1% | 1200Kg ±1% | 1800Kg ±1% | 2200Kg ±1% | |
| Fly ash(KG) | 600Kg ±1% | 900Kg ±1% | 400Kg ±1% | 500Kg ±1% | 800Kg ±1% | |
| Water (KG) | 600Kg ±1% | 600Kg ±1% | 500Kg ±1% | 800Kg ±1% | 1000Kg ±1% | |
| Additive(KG) | 50Kg ±1% | 50Kg ±1% | 50Kg ±1% | 80Kg ±1% | 80Kg ±1% | |
| Total power(KW) | 120Kw | 165Kw | 130Kw | 170KW | 220KW | |
| Discharging height(M) | 3.8 m | 4.1 m | 4.1m | 4.1m | 4.1m | |
